Electronics Benchtop

The IDC contains a suite of electronics benchtop equipment available to all end users.

Each standard station includes an:

• Oscilloscope
• Function generator
• Multimeter
• Power supply
• Soldering station, complete with a soldering iron and desoldering tool.

When you check out a station, you gain access to drawers with additional hand tools, such as tweezers, wire cutters, and screw drivers, to help you in your project.

Beginner guides on to use each piece of equipment are listed below:

• Oscilloscope guide
• Function generator guide
• Multimeter guide
• Power supply guide (Planned)
• Soldering guide (Planned)

In addition we also have video demos listed for all of these different pieces of equipment found here:

• Intro To Electronics Prototyping

  This video introduces breadboards, multi-meters, and other tools needed to start prototyping electronics.

• Intro To Soldering

  Here we talk about what soldering is, the basics of the soldering iron and solder, and how to do through hole soldering.

• Waveform Generator

  Stevie shows you how to use the Waveform Generator found on most benches.

• DMM and Power Supply

  Stevie shows you how to use the DC power supply and Digital multi meter located on most of the benches.

• Oscilloscope How-To

  In this video, Stevie shows you how to use the oscilloscope, a tool that tells you voltage over time at a sample rate of 5 billion times a second.

Full List of Benchtop Equipment

The following is provided in no particular order.

Name	Image
Keithley source meter 2450
Keithley digital multimeter DMM6500
Tektronix oscilloscope MSO58
Tektronix function generator AFG31152
Keithley precision supply and battery simulator 2281S-20-6
Keithley triple output power supply 2230-30-1
Keysight LCR meter E4980-AL
Keysight power meter N1913A
Keysight triple power supply U8031A (2x 0-30V, 6A; 1x 5V, 3A)
Keysight digital multimeter 34460A
Keysight waveform generator 33500B
Keysight oscilloscope DSOX3014A
Keysight oscilloscope DSOX4024A
Keysight oscilloscope DSOX6002A
Keysight network analyzer E5063A
Keysight signal analyzer N9000B
Keysight vector signal generator
Keysight triple power supply, low power E3630A (0-6V, 2.5A; 0-20V, 0.5V; 0-(-20)V, 0.5A)
Aoyue vacuum pick-up hand tool 932
Weller soldering iron and solder sucker WXR3
Quick hot-air rework station 957DW+
